Subminiature, LAN Modular Jack Connectors
TM11R-5M2 Series
s Features
1.Fast Ethernet Support
Conforms to the TIA/EIA-568-A data wiring standard and
meets requirements of CAT5 transmission performance
for 1,2-3,6 conductor pairs. As such, these products fully
support Fast Ethernet (100BASE-TX) transmission.
16
24
21
2. Subminiature Design Contributes to Saving
Space in the Equipment
Having built-in optical indicators, with height of only
Other series
TM21R--5C--88--LP
17.5
11.5mm, width of 15mm and depth of 17.5mm the
connectors can be used in extremely limited spaces.
3. Built-in Optical Indicators
Optical indicators are integral part of the connectors help
saving space on customer’s board.
Compared with LED type indicators, they do not emit any
electrical noise.
4. EMI protection
Metal shield covers the outer surfaces of the connectors
TM11R--5M2--88--LP
Space saving
15
14.5
assuring complete protection against electromagnetic
interference.
Built-in multiple shield and ground contacts assure
reliable connection with the mounting panel as well as
with the mating connectors.
5. Environmental considerations
Plating is lead-free in order to protect environment.
6. FCC Standards
Meets requirements of FCC Title 47, Part 68, Subpart F.
s Applications
Telecom Hubs, Routers, Bridges and ATM Transmission
Equipment, Ethernet Switches and Networking Equipment,
Test and Measurement Equipment, Medical Diagnostic
Equipment.
housing
EMI protection
Built-in LED type
(Possibility of electromagnetic
LED optical indicators are taking place
Built-in Optical pipe type
(No electromagnetic
noise emission and interference.)
noise emission.)
2012.6
1
